Product features
MULTI FUNCTIONS & LOW IMPEDANCE MEASUREMENT
- LM3001 Clamp Multimeter can accurately measure AC Current to 200A,
AC/DC Voltage to 600V,frequency to 1000Hz,resistance to 60MΩ,capacitance
to 6000μF, temperature, line ON/OFF, Sampling times at approx. 3
time/sec; low impedance measurement for more accurate current
measurement
RELATIVE MEASUREMENT & DUAL MEASURING MODEL-
with the REL function,get more accurate measuring data through
deviation value; and LM3001 Clamp Multimeter has the select measurement
function and auto-ranging,it is perfect for both professional user and
newer
TRMS &DATA HOLD - TRMS 6000 counts
meter make the measure more accurate to a certain level than traditional
measurement; with the data hold function, the reading can be locked in
the meter LCD screen
OVERLOAD PROTECTION AND AUTO POWER OFF FUNCTION
- the multimeter will not be easily destroyed by overload test for
overload protection, and the meter will auto power off after 20 mins's
no operation to save energy
CONTINUITY TEST & OVERLOAD PROTECTION:
Designed to Safely and Accurately Confirm the Circuit Conducts
Electricity with Low Voltage Indication and Overload Protection. Light
Alarm If Detects the AC Voltage(0V-600V) or Live Wire.Shows "OL" on the
LCD If Overload
Product description
Special attention shall be paid when
using the meter, improper use might cause an electric shock or damage
the meter. General safety procedures shall be followed during the use
and safety measures regulated by the instruction manual shall be
completely respected.
over-voltage standard is CATIII 300V, CATII 600V.
- General protection against electric shock - Prevent misuse of the meter.
-After received the meter, check if it has been damaged during the delivery.
-After been kept and delivered in shoddy conditions, check and confirm if the meter is damaged or not.
-The clamp meter must be in good condition. Before use, check
-the clamp meter see if any damage to the insulation, if the metal wire of the cable is bare.
Specification:
-DC Current Range and Accuracy: 0-200μA ±(0.8%+5counts)
-AC Current Range and Accuracy: 0-200A ±(2.5%+5counts)
-DC Voltage Range and Accuracy: 0-600V ±(1.0%+3counts)
-AC Voltage Range and Accuracy: 0-600V ±(1.0%+3counts)
-Frequency Range and Accuracy: 0-1000Hz ±(1.0%+5counts)
-Low impedance Loz (AC and DC) and Accuracy: 0-600V ±1.0%
-Resistance Range and Accuracy: 0-60MΩ ±(1.2%+20counts)
-Capacitance Range and Accuracy: 0-6000μF ±(4%+3counts)
-Temperature Range and Accuracy: -20 ~ 500 ℃ (-4 ~ 932 ℉) ±(2%+2counts)
-Display: 6000 counts
-Power supply: 2×1.5V AAA battery (included)
-Dimension:179* 67* 36 mm
-Weight: ~137g
Package included:
1x LIUMY LM3001 digital clamp meter
2x Test Lead
1x Temperature Probe
2x 1.5V AAA Batteries
1x English User Manual
1x Black Soft Carry Pouch
